The Perkins® 4000 Series family of 6, 8, 12 and 16 cylinder diesel engines was designed in advance of today’s
uncompromising demands within the power generation industry and includes superior performance and reliability.
The 4008TAG2A is a turbocharged and air-to-air charge cooled, 8 cylinder diesel engine offered with either temperate or tropical cooling. Its premium features and design provide economic and durable operation as well as an exceptional power to weight ratio, excellent load acceptance and improved gaseous emissions, plus the overall performance and reliability characteristics essential to the power generation market.
Make: PERKINS
Model Number: 4008-TAG2A
Prime Power: 1000 kVA
Standby Power: 1100 kVA
Voltage: 230V / 400V
Phase: THREE PHASES
AMP @ Unity: 1146 A
AMP @ 0.8PF: 1440 A
ONE Step Load: 55% OF AMP RATING
Features:
• Individual 4 valve cylinder heads giving optimised gas flows
• Unit fuel injectors ensure ultra fine fuel atomisation and hence controlled rapid combustion
• Commonality of components with other engines in the 4000 Series family for reduced stocking levels
• Capable emissions of 1/2 TA Luft (1986)
General Specifications:
Standard stainless-steel exhaust with silencer
Personalised specifications can be accommodated.
Base frame design incorporates an integral fuel tank
Ventilation parts are designed with modular principles
Includes diesel level sensor and information to the controller
Coastal antirust stainless-steel options are available for the canopy
Standard filler cap and fuel level gauge is located inside the canopy
All canopies are weather resistant and lined with sound reduction foam
Canopies are all metal and powder-coated, equipped with lockable doors
Engine Specifications:
Fuel connection hoses
Cooling radiator and fan
Heavy duty diesel engine
DC starter and charge alternator
Replaceable fuel filter, oil filter and dry element air filter fuel connection hoses
Warranty Specifications:
Qualified support team on standby.
Installations to be done by qualified persons only
Service every 250 hours or annually, whichever occurs first
Unit to be used as a standby power supply and not a main power supply
Maintenance contracts are available on request – we have various options on offer.
If the installation is done by IGNITE Petroleum an additional 6 months will be added to the standard 1 year warranty
Standard 2 year or 1000 hours warranty on engine and a 1-year warranty on the rest of the set – valid from the day of dispatch
Optional Specifications:
Optional synchronizing for kVA requirements larger than 600 we suggest you consider synchronization as an option.
- When busy with maintenance other sets can still provide power
- It is more cost effective for the purchase price, maintenance and fuel consumption
- If underload, glazing will be prevented due to the effective control on the sets by regulating and managing the load requirements and switching between sets automatically
Our highly trained team will be on standby and will ensure the system is designed to meet all your requirements.
Optional Control Functions:
All controller makes and models are available
External siren and light are available on request
GSM modems are available for SMS and remote-control
All circuits can be designed to meet specified requirements
Optional:
Island mode – only available for sets larger than 150kva
In most manufacturing systems any electrical supply interruption can result in large material and production losses. this nightmare can be resolved during scheduled power outages with the ‘no brake system’ known as island mode. this is a plc-controlled system designed with the most advanced technology.
Our advanced, UK trained team, will design and manufacture this system to meet all your requirements.
Available colours:
Standard Colours: Black | Grey | Charcoal | White | Avo Green
Custom Colours: All colours can be accommodated based on the available drum powder coating
Our other generator brands include:
FAW, Volvo, Perkins, Kirloskar, LOVOL, Scania (depending on the kVA).
Data sheets are available upon request, and rental options are offered for specific models of complete generators.
